Product Description
ICM Control Gas Ignition Control Module Part Number ICM288
Replacement for the following number: Rheem number 62-24084-82
Features:
- Microprocessor-based design
- Monitors pressure, roll-out and limit switches
- Controls gas valve, inducer draft motor, circulating blower and hot surface ignitor
- Reverse polarity detection
- Twinning compatible with other ICM288 control boards
- Diagnostic LEDs for testing/troubleshooting
- Low cost form, fit and functional replacement board for Goodman B18099-04
- Controls inducer and blower control
- Microprocessor-based
- Designed for 100% gas shutoff in case of ignition failure
- Monitors timing and gas valve
- Diagnostic LEDs aid in testing / troubleshooting
Specifications:
- Voltage Range: Line 98-132 VAC @ 60HZ
- Ignitor: 5A, 120 VAC
- Cool Blower: 10A, 2HP, 240 VAC
- Heat: 5A, 1/2 HP, 250 VAC
- Inducer Blower: 4A, 120 VAC
- Gas Valve: 1A, 24 VAC
- Humidifier Motor: 0.5A, 24 VAC
- Electronic Air Cleaner: 1A, 120 VAC
